Desktop Gateway RG5100

TRNF: Type-C/DC5V1A

Remote Control Local Scenario Device Linkage Batch Access to Network

RG5100 is a desktop gateway based on the Rexense RG5011 gateway core board, combined with COO module. RG5100 integrates multiple communication methods including Zigbee, Ethernet, and Wi-Fi 6, providing a complete, high-performance, and cost-effective gateway system that complies with the IEEE802.15.4 specification and Zigbee 3.0 protocol standards, and has complete gateway functionality.

Consult immediately

Scheme Advantages Core functions Gateway architecture Application scenario Product specifications

Scheme Advantages

High Robustness

Through the in-depth optimization of the underlying routing algorithm of the protocol, the stability of multi-node device networking is improved, and the low packet loss rate and low delay are guaranteed under high throughput.
High Performance

Equipped with a self-developed module, the excellent module RF performance ensures a communication distance of >300 meters in an open environment and stronger signal penetration capabilities
High Reliability

Relying on professional hardware design capabilities and strict testing process standards, the solution can ensure the high consistency of factory gateway quality and long-term reliable operation in harsh environments
High Usability

Supporting complete Zigbee functionality and gateway application functionality, customers only need to configure files to achieve cloud platform integration, reducing development barriers.
High Efficiency

The solution supports batch network access, provides networking configuration tools, supports construction deployment in no-network environments, greatly improves construction efficiency and reduces construction costs

Core functions

OTA

Support OTA online upgrade of the software in each link from the gateway to the sub-device
Edge Calculation

Equipped with edge computing capabilities, the gateway can realize data processing without the cloud, and it can also realize the linkage of local scenes of devices in a no-network environment
Fault Diagnosis

Checking routing topology and neighbor relationships through diagnostic tools to quickly locate faults
Migrating Devices

Only takes 3 quick steps to realize the synchronous migration of sub-devices and related scene functions under the original gateway to the new gateway
